3D surface plot
Level 2 Category
Definition
Shows the relationship between three variables as a smooth surface. It's a useful tool for exploring how variables interact.
Example Image
Reproduced from IEEE Access, vol. 10, pp. 27535-27549, 2022. https://doi.org/10.1109/ACCESS.2022.3157629. Licensed under CC BY 4.0.
Writing Alternative Text
Describe the variables, the shape of the surface, and any notable peaks, valleys, or gradients across the plot.
Example Alt Text
"Two three-dimensional surface plots show voltage as a function of current and geometry. In panel a, voltage is about 28 volts at low airgap width and falls steeply as airgap width increases toward 3 millimeters, with a smaller change across current from 0 to 7 amperes. In panel b, voltage rises from about 22 to 31 volts as P M height increases from 0 to 25 millimeters, while increasing current slightly lowers voltage."
