Neural network
Level 2 Category
Definition
A layered diagram showing data flows as lines between interconnected circles or dots representing nodes or neurons.
Example Image
Reproduced from Science Progress, 104(3). https://doi.org/10.1177/00368504211026111. Licensed under CC BY-NC 4.0.
Writing Alternative Text
Describe the layers or nodes involved, the connections that pass information between them, and any notable patterns, weights, or structural features.
Example Alt Text
"Two neural network diagrams compare related architectures. In both panels, multiple input nodes connect to RBF kernel mapping nodes labelled phi 1 through phi K, each followed by a double-polar block. Panel a connects these blocks to one fully connected BP hidden layer of sigmoid nodes and then to multiple outputs. Panel b adds a second fully connected sigmoid hidden layer before the outputs. Ellipses indicate additional repeated nodes."
